HEDWIG
Collection of measurement data to assess the impact of green buildings

HEDWIG aims for the assessment of effects from green roofs and facades on buildings by using monitoring data referring to microclimate and building physics. The objective is to define validated vegetation parameters and performance indicators on indoor and outdoor level and on microclimatic relevant street space level. Standardised indicators, evaluation and analysis procedures will be elaborated.

ResearchMonitoring

The effects and benefits of Green Infrastructure have become a global research interest. However, reliable data on the effects, especially of building greening, are still not available.

The study "Effects of the Green City" (Stangl et al. 2019) provided an overview of the international state of knowledge on measurable effects and parameters of greening measures. Cooling effects and the associated energy savings often are the focus of scientific work, and the spectrum of parameters collected, is wide. Still, inaccurate representations and information on the underlying data or measurement setups, the non-comparability of the published parameters and the lack of causal relationships are problematic.

Overall, the state of knowledge is still fragmented and contradictory, reducing the information value of even up-to-date studies and results. For example, there are not yet characteristic values available for the integration in the energy certificate for greening buildings. Investments in GI are often controversial, as evidence of the benefits versus the costs is lacking.

The HEDWIG project aims to determine the effects of standard-compliant building greening (green roofs and facades) in the course of permanent monitoring. Sound and resilient vegetation and performance parameters will be obtained and related to the effects of building greening on the indoor climate and the exterior microclimate.

HEDWIG develops and verifies a measurement setup suitable for the collection of valid data, their comparability and the evaluation of Green Infrastructure demonstration projects. HEDWIG collects microclimatic and building physical data from 15 representative green buildings with heterogeneous age structures and different types of use. Measurement campaigns and continuous measurements will be applied over two years. Parameters such as transmissivity of climbing plants, heat flux through green roof structures or indoor thermal comfort are recorded in a structured and standardized way.

This allows for developing standard parameters for green infrastructure typologies and transfer them to planning and implementation processes. The measurements are supplemented and supported by thermal building simulations. A data evaluation procedure will be developed and standardized to enable cross-site comparisons. Periodically occurring effects as well as favorable and disruptive influencing factors will be identified and made calculable.

New findings are in particular expected on the microclimatic influence of green bodies on the building envelope and the interior. An optional objective is assessment of microclimatic effects for the adjacent street space and urban area.

The HEDWIG measurement and analysis methodology will be documented in a comprehensible way and made available as open content for future research and demonstration projects. The findings from the key values and effects should enable the further development of calculation models, promote the further mainstreaming of green buildings and form the basis for argumentation and approval processes.

Project team

University of Natural Resources and Life Sciences (BOKU), Institute of Soil-­Bioengineering and Landscape Construction (project lead)

RED Bernard GmbH

IBO GmbH

GRÜNSTATTGRAU

Research period

October 2022 – September 2025

Funding Institutions

"Stadt der Zukunft" is a research and technology programme of the Federal Ministry for Climate Action, Environment, Energy, Mobility, Innovation and Technology. It is carried out on behalf of the BMK by the Austrian Research Promotion Agency (FFG) together with the Austria Wirtschaftsservice Gesellschaft mbH (AWS) and the Austrian Society for Environment and Technology (ÖGUT).
